Alto tesso discarico batteria litio polimeri 3.7V 5C - 50C

    Voto C Corrente di scarica descrive come rapidamente una batteria litio polimeri può essere scaricata. Un 3000mAh batteria litio polimeri con rating C di continuo 1C significa che non devono essere scaricati più velocemente di qualsiasi 3000mA (3A), che avrebbe preso un'ora. Un pack 2000mAh nominale 5C continuo sarebbe in grado di adempiere a 5 volte la sua capacità (5 x = 3000mA 15000mA o 15A) in cui aliquota sarebbe discarico 1/5th di un'ora. Utilizzando un pacchetto con un rating superiore C di quello che sarà necessario lasciare un certo margine di sicurezza, e prolungare la durata della batteria litio polimeri.

    Batteria litio polimeri corrente continua
    Se si conosce la quantità di corrente continua saranno scelte e la capacità della confezione che si desidera utilizzare, si può facilmente determinare quali rating C avete bisogno. Se si sta disegnando 5A da un pacco da 2000mAh, basta seguire la corrente e dividere per il 5A = 5000mA, 5000mA / 2000mAh = 2.5C.

    Batteria litio polimeri burst corrente
    batteria ai polimeri di litio è anche dato un rating C in termini di scoppio, che è quanto velocemente la batteria è in grado di scaricare per un breve periodo. Una raffica di rating 10C significherebbe una batteria di 3000mAh potrebbero fornire il 10 x = 3000mA 30000mA o 30A per alcuni secondi.

    Per selezionare le migliori la batteria litio polimeri per il tuo elicottero RC
    Per selezionare una batteria litio polimeri per il vostro elicottero RC, bisogna prima sapere che cosa avete bisogno di tensione e quanta corrente ti verrà disegno continuo. Se il motore in vostro elicottero RC è valutato a lavorare con 14.8V, avreste bisogno di una batteria litio polimeri a 4 celle. Se avete bisogno di disegnare 10A, e vorresti che il tuo elicottero RC di avere un 10 minuti (1/6th di un'ora = 6C) volo, si avrebbe bisogno di una batteria con 10A / 6 = 1,7 = 1700mAh. Questo significa che si avrebbe bisogno di mettere un 3s 1700mAh batteria litio polimeri con un rating C di 6 o più alto in vostro elicottero RC.

    Alta Scarico C-rating Batteria Litio Polimeri
    spessore 2.5mm to 2.8mm, 40mAh to 220mAh, 1C to 2C

    Modello lunghezza
    (mm)
    Altezza
    (mm)
    spessore
    (mm)
    C-rating capacità
    (mAh)
    tensione
    (V)
    LPHD250830 30 8 2.5 1 40 3.7
    LPHD252848 48 28 2.5 1 220 3.7
    LPHD253048 48 30 2.5 1 220 3.7
    LPHD280819 19 8 2.8 1 27 3.7



    Alta Scarico C-rating Batteria Litio Polimeri
    spessore 3.2mm to 3.9mm, 70mAh to 5660mAh, 1C to 30C

    Modello lunghezza
    (mm)
    Altezza
    (mm)
    spessore
    (mm)
    C-rating capacità
    (mAh)
    tensione
    (V)
    LPHD321429 29 14 3.2 10 70 3.7
    LPHD334969 69 49 3.3 1 1200 3.7
    LPHD354883 83 48 3.5 5 1400 3.7
    LPHD361745 45 17 3.6 15 150 3.7
    LPHD3634101 101 34 3.6 30 1000 3.7
    LPHD372438 38 24 3.7 1 380 3.7
    LPHD372629 29 26 3.7 1 220 3.7
    LPHD382438 38 24 3.8 1 410 3.7
    LPHD3967182 182 67 3.9 1 5660 3.7
    LPHD3994129 129 94 3.9 1 5600 3.7



    Alta Scarico C-rating Batteria Litio Polimeri
    spessore 4.0mm to 4.9mm, 80mAh to 4000mAh, 15C to 30C

    Modello lunghezza
    (mm)
    Altezza
    (mm)
    spessore
    (mm)
    C-rating capacità
    (mAh)
    tensione
    (V)
    LPHD401935 35 19 4 15 160 3.7
    LPHD401940 40 19 4 15 200 3.7
    LPHD403048 48 30 4 20 300 3.7
    LPHD403048 48 30 4 20 350 3.7
    LPHD403048 48 30 4 30 450 3.7
    LPHD403438 38 34 4 1 520 3.7
    LPHD403496 96 34 4 15 1100 3.7
    LPHD403496 96 34 4 20 1000 3.7
    LPHD404385 85 43 4 10 1250 3.7
    LPHD4144120 120 44 4.1 30 1800 3.7
    LPHD421035 35 10 4.2 15 80 3.7
    LPHD422030 30 20 4.2 5 160 3.7
    LPHD422030 30 20 4.2 20 110 3.7
    LPHD422030 30 20 4.2 10 150 3.7
    LPHD423455 55 34 4.2 1 800 3.7
    LPHD424360 60 43 4.2 1 1000 3.7
    LPHD4344100 100 44 4.3 10 1600 3.7
    LPHD443048 48 30 4.4 15 480 3.7
    LPHD443048 48 30 4.4 20 450 3.7
    LPHD443085 85 30 4.4 20 700 3.7
    LPHD4434106 106 34 4.4 20 1300 3.7
    LPHD444694 94 46 4.4 1 1500 3.7
    LPHD445265 65 52 4.4 5 1500 3.7
    LPHD446586 86 65 4.4 25 2200 3.7
    LPHD451945 45 19 4.5 15 250 3.7
    LPHD4520122 122 20 4.5 15 800 3.7
    LPHD452530 30 25 4.5 20 200 3.7
    LPHD452535 35 25 4.5 20 250 3.7
    LPHD453048 48 30 4.5 20 430 3.7
    LPHD453142 42 31 4.5 20 400 3.7
    LPHD453450 50 34 4.5 1 750 3.7
    LPHD453496 96 34 4.5 20 1300 3.7
    LPHD462845 45 28 4.6 20 450 3.7
    LPHD462845 45 28 4.6 30 450 3.7
    LPHD4642126 126 42 4.6 20 2000 3.7
    LPHD471950 50 19 4.7 15 300 3.7
    LPHD471955 55 19 4.7 15 350 3.7
    LPHD472530 30 25 4.7 15 230 3.7
    LPHD473040 40 30 4.7 20 350 3.7
    LPHD473048 48 30 4.7 25 450 3.7
    LPHD473048 48 30 4.7 20 450 3.7
    LPHD473976 76 39 4.7 5 1550 3.7
    LPHD481530 30 15 4.8 20 120 3.7
    LPHD4819160 160 19 4.8 15 1300 3.7
    LPHD483030 30 30 4.8 5 300 3.7
    LPHD483048 48 30 4.8 20 500 3.7
    LPHD4834106 106 34 4.8 20 1450 3.7
    LPHD483496 96 34 4.8 20 1200 3.7
    LPHD483496 96 34 4.8 10 1450 3.7
    LPHD483562 62 35 4.8 20 650 3.7
    LPHD484360 60 43 4.8 20 1050 3.7
    LPHD4849135 135 49 4.8 15 3200 3.7
    LPHD493496 96 34 4.9 30 1400 3.7
    LPHD4945160 160 45 4.9 5 4000 3.7



    Alta Scarico C-rating Batteria Litio Polimeri
    spessore 3.2mm to 3.9mm, 120mAh to 5700mAh, 15C to 35C

    Modello lunghezza
    (mm)
    Altezza
    (mm)
    spessore
    (mm)
    C-rating capacità
    (mAh)
    tensione
    (V)
    LPHD501140 40 11 5 15 120 3.7
    LPHD5016185 185 16 5 20 1300 3.7
    LPHD501795 95 17 5 15 650 3.7
    LPHD5019160 160 19 5 15 1300 3.7
    LPHD501940 40 19 5 10 280 3.7
    LPHD5020100 100 20 5 15 850 3.7
    LPHD502035 35 20 5 20 230 3.7
    LPHD503030 30 30 5 1 390 3.7
    LPHD503030 30 30 5 10 300 3.7
    LPHD503048 48 30 5 25 500 3.7
    LPHD5034100 100 34 5 15 1500 3.7
    LPHD503476 76 34 5 20 1000 3.7
    LPHD503496 96 34 5 20 1050 3.7
    LPHD503496 96 34 5 30 1200 3.7
    LPHD503562 62 35 5 20 800 3.7
    LPHD503562 62 35 5 10 1000 3.7
    LPHD5042126 126 42 5 30 2400 3.7
    LPHD504358 58 43 5 5 1400 3.7
    LPHD5045150 150 45 5 25 2650 3.7
    LPHD504964 64 49 5 1 1800 3.7
    LPHD505180 80 51 5 1 2200 3.7
    LPHD5080125 125 80 5 8 5250 3.7
    LPHD513048 48 30 5.1 25 600 3.7
    LPHD513562 62 35 5.1 1 1200 3.7
    LPHD5219160 160 19 5.2 25 1250 3.7
    LPHD5234122 122 34 5.2 10 2100 3.7
    LPHD523460 60 34 5.2 10 930 3.7
    LPHD523496 96 34 5.2 15 1500 3.7
    LPHD523562 62 35 5.2 15 1000 3.7
    LPHD5242126 126 42 5.2 20 2600 3.7
    LPHD524285 85 42 5.2 15 2000 3.7
    LPHD524380 80 43 5.2 8 1800 3.7
    LPHD524694 94 46 5.2 20 1500 3.7
    LPHD524694 94 46 5.2 10 1600 3.7
    LPHD524969 69 49 5.2 1 2000 3.7
    LPHD5267100 100 67 5.2 5 4000 3.7
    LPHD527096 96 70 5.2 5 4000 3.7
    LPHD532030 30 20 5.3 15 210 3.7
    LPHD533496 96 34 5.3 15 1500 3.7
    LPHD533496 96 34 5.3 35 1400 3.7
    LPHD533562 62 35 5.3 15 900 3.7
    LPHD5342124 124 42 5.3 15 2700 3.7
    LPHD5342124 124 42 5.3 20 2500 3.7
    LPHD5342126 126 42 5.3 20 2400 3.7
    LPHD5342126 126 42 5.3 30 2600 3.7
    LPHD5343128 128 43 5.3 20 2400 3.7
    LPHD5345135 135 45 5.3 20 3000 3.7
    LPHD5346143 143 46 5.3 20 3300 3.7
    LPHD543082 82 30 5.4 1 1500 3.7
    LPHD543351 51 33 5.4 10 800 3.7
    LPHD543496 96 34 5.4 20 1050 3.7
    LPHD5442126 126 42 5.4 15 2900 3.7
    LPHD544280 80 42 5.4 20 1600 3.7
    LPHD5443128 128 43 5.4 20 2500 3.7
    LPHD544473 73 44 5.4 1 2000 3.7
    LPHD5446143 143 46 5.4 20 3200 3.7
    LPHD544694 94 46 5.4 20 1600 3.7
    LPHD544992 92 49 5.4 20 1650 3.7
    LPHD5459156 156 59 5.4 5 5700 3.7
    LPHD546474 74 64 5.4 25 1700 3.7
    LPHD551130 30 11 5.5 15 110 3.7
    LPHD551628 28 16 5.5 10 150 3.7
    LPHD551675 75 16 5.5 20 530 3.7
    LPHD551675 75 16 5.5 10 630 3.7
    LPHD5517130 130 17 5.5 20 1080 3.7
    LPHD551768 68 17 5.5 15 500 3.7
    LPHD551795 95 17 5.5 20 780 3.7
    LPHD5519160 160 19 5.5 15 1400 3.7
    LPHD551996 96 19 5.5 15 850 3.7
    LPHD551996 96 19 5.5 15 950 3.7
    LPHD5520122 122 20 5.5 15 1080 3.7
    LPHD5520122 122 20 5.5 30 950 3.7
    LPHD5520122 122 20 5.5 30 1100 3.7
    LPHD5520122 122 20 5.5 15 1200 3.7
    LPHD552030 30 20 5.5 1 200 3.7
    LPHD552030 30 20 5.5 20 180 3.7
    LPHD5530100 100 30 5.5 25 1250 3.7
    LPHD553048 48 30 5.5 15 600 3.7
    LPHD553048 48 30 5.5 20 600 3.7
    LPHD553085 85 30 5.5 15 1200 3.7
    LPHD553085 85 30 5.5 20 1100 3.7
    LPHD5534100 100 34 5.5 20 1750 3.7
    LPHD553496 96 34 5.5 15 1500 3.7
    LPHD553496 96 34 5.5 20 1400 3.7
    LPHD553496 96 34 5.5 30 1650 3.7
    LPHD553562 62 35 5.5 30 1000 3.7
    LPHD5536110 110 36 5.5 1 2500 3.7
    LPHD5542124 124 42 5.5 20 2800 3.7
    LPHD5542126 126 42 5.5 15 2900 3.7
    LPHD5542126 126 42 5.5 35 2700 3.7
    LPHD5542126 126 42 5.5 5 3500 3.7
    LPHD5542126 126 42 5.5 15 2850 3.7
    LPHD5542126 126 42 5.5 20 2750 3.7
    LPHD5543128 128 43 5.5 20 2500 3.7
    LPHD5545150 150 45 5.5 20 3200 3.7
    LPHD5551143 143 51 5.5 10 4200 3.7
    LPHD555180 80 51 5.5 1 2500 3.7
    LPHD5559156 156 59 5.5 5 5700 3.7
    LPHD556094 94 60 5.5 1 3300 3.7
    LPHD556479 79 64 5.5 15 2800 3.7
    LPHD556586 86 65 5.5 5 3500 3.7
    LPHD5620122 122 20 5.6 15 1100 3.7
    LPHD562464 64 24 5.6 10 800 3.7
    LPHD563048 48 30 5.6 15 630 3.7
    LPHD563476 76 34 5.6 8 1650 3.7
    LPHD563496 96 34 5.6 25 1650 3.7
    LPHD563496 96 34 5.6 15 1700 3.7
    LPHD563562 62 35 5.6 30 1000 3.7
    LPHD5642126 126 42 5.6 25 2850 3.7
    LPHD5642126 126 42 5.6 15 3000 3.7
    LPHD5642126 126 42 5.6 40 2400 3.7
    LPHD564280 80 42 5.6 15 1900 3.7
    LPHD564280 80 42 5.6 8 2100 3.7
    LPHD5645135 135 45 5.6 15 3300 3.7
    LPHD5653105 105 53 5.6 30 2900 3.7
    LPHD5665126 126 65 5.6 5 5200 3.7
    LPHD571636 36 16 5.7 20 200 3.7
    LPHD573496 96 34 5.7 20 1500 3.7
    LPHD573562 62 35 5.7 15 1000 3.7
    LPHD5742126 126 42 5.7 30 2500 3.7
    LPHD574280 80 42 5.7 15 1950 3.7
    LPHD574283 83 42 5.7 15 2150 3.7
    LPHD574283 83 42 5.7 20 2050 3.7
    LPHD574285 85 42 5.7 8 2500 3.7
    LPHD574285 85 42 5.7 20 2000 3.7
    LPHD574285 85 42 5.7 15 2150 3.7
    LPHD574285 85 42 5.7 20 2050 3.7
    LPHD574285 85 42 5.7 20 1950 3.7
    LPHD574380 80 43 5.7 15 1930 3.7
    LPHD574380 80 43 5.7 20 1800 3.7
    LPHD574380 80 43 5.7 30 1600 3.7
    LPHD5753105 105 53 5.7 20 2900 3.7
    LPHD581130 30 11 5.8 15 120 3.7
    LPHD581147 47 11 5.8 20 200 3.7
    LPHD581640 40 16 5.8 15 240 3.7
    LPHD581855 55 18 5.8 25 420 3.7
    LPHD5820122 122 20 5.8 15 1100 3.7
    LPHD583040 40 30 5.8 1 600 3.7
    LPHD583048 48 30 5.8 15 770 3.7
    LPHD583048 48 30 5.8 15 650 3.7
    LPHD583048 48 30 5.8 20 620 3.7
    LPHD583060 60 30 5.8 20 600 3.7
    LPHD583496 96 34 5.8 25 1500 3.7
    LPHD583562 62 35 5.8 20 1000 3.7
    LPHD5836128 128 36 5.8 15 2800 3.7
    LPHD5836128 128 36 5.8 20 2200 3.7
    LPHD5842126 126 42 5.8 20 2200 3.7
    LPHD5842126 126 42 5.8 20 2600 3.7
    LPHD5842126 126 42 5.8 30 2800 3.7
    LPHD5842126 126 42 5.8 25 2200 3.7
    LPHD584280 80 42 5.8 5 2280 3.7
    LPHD584285 85 42 5.8 20 2000 3.7
    LPHD584285 85 42 5.8 8 2400 3.7
    LPHD5843128 128 43 5.8 20 2700 3.7
    LPHD5843128 128 43 5.8 30 2600 3.7
    LPHD5844175 175 44 5.8 20 4000 3.7
    LPHD584473 73 44 5.8 1 2000 3.7
    LPHD5845135 135 45 5.8 20 3000 3.7
    LPHD5845150 150 45 5.8 20 3400 3.7
    LPHD5845150 150 45 5.8 25 3200 3.7
    LPHD584973 73 49 5.8 15 2000 3.7
    LPHD585180 80 51 5.8 1 2800 3.7
    LPHD5865132 132 65 5.8 5 5250 3.7
    LPHD5870135 135 70 5.8 1 5900 3.7
    LPHD587260 60 72 5.8 20 2150 3.7
    LPHD592976 76 29 5.9 8 1250 3.7
    LPHD593048 48 30 5.9 15 650 3.7
    LPHD593476 76 34 5.9 20 1400 3.7
    LPHD593482 82 34 5.9 20 1500 3.7
    LPHD593496 96 34 5.9 25 1800 3.7
    LPHD593562 62 35 5.9 25 1100 3.7
    LPHD5938115 115 38 5.9 30 2400 3.7
    LPHD5945150 150 45 5.9 20 3500 3.7
    LPHD5946143 143 46 5.9 20 3800 3.7
    LPHD5946143 143 46 5.9 30 3800 3.7
    LPHD596078 78 60 5.9 30 2500 3.7
    LPHD5967105 105 67 5.9 1 3300 3.7



    Alta Scarico C-rating Batteria Litio Polimeri
    spessore 6.0mm to 6.9mm, 160mAh to 15500mAh, 1C to 30C

    Modello lunghezza
    (mm)
    Altezza
    (mm)
    spessore
    (mm)
    C-rating capacità
    (mAh)
    tensione
    (V)
    LPHD601140 40 11 6.0 15 160 3.7
    LPHD601640 40 16 6.0 15 280 3.7
    LPHD601662 62 16 6.0 15 430 3.7
    LPHD601795 95 17 6.0 20 750 3.7
    LPHD601844 44 18 6.0 20 300 3.7
    LPHD6020122 122 20 6.0 15 1350 3.7
    LPHD6020122 122 20 6.0 20 1150 3.7
    LPHD602030 30 20 6.0 1 300 3.7
    LPHD602030 30 20 6.0 10 200 3.7
    LPHD602442 42 24 6.0 15 500 3.7
    LPHD602442 42 24 6.0 15 450 3.7
    LPHD602464 64 24 6.0 10 850 3.7
    LPHD602486 86 24 6.0 15 1080 3.7
    LPHD603048 48 30 6.0 20 650 3.7
    LPHD603060 60 30 6.0 20 850 3.7
    LPHD603085 85 30 6.0 15 1300 3.7
    LPHD603085 85 30 6.0 20 1250 3.7
    LPHD603351 51 33 6.0 20 850 3.7
    LPHD603482 82 34 6.0 10 1550 3.7
    LPHD603496 96 34 6.0 20 1600 3.7
    LPHD603496 96 34 6.0 15 1800 3.7
    LPHD6036128 128 36 6.0 20 2200 3.7
    LPHD6038110 110 38 6.0 30 2200 3.7
    LPHD6042124 124 42 6.0 20 2800 3.7
    LPHD6042126 126 42 6.0 10 3500 3.7
    LPHD6043128 128 43 6.0 30 2500 3.7
    LPHD6044175 175 44 6.0 20 4000 3.7
    LPHD604694 94 46 6.0 20 1800 3.7
    LPHD6053105 105 53 6.0 25 2900 3.7
    LPHD605582 82 55 6.0 30 2500 3.7
    LPHD605998 98 59 6.0 5 4000 3.7
    LPHD606078 78 60 6.0 1 2400 3.7
    LPHD606078 78 60 6.0 20 2550 3.7
    LPHD606078 78 60 6.0 20 2500 3.7
    LPHD606164 64 61 6.0 1 2500 3.7
    LPHD6063135 135 63 6.0 1 5000 3.7
    LPHD6072196 196 72 6.0 8 8900 3.7
    LPHD6072200 200 72 6.0 10 9000 3.7
    LPHD6088106 106 88 6.0 1 5000 3.7
    LPHD612548 48 25 6.1 5 700 3.7
    LPHD612548 48 25 6.1 5 700 3.7
    LPHD6134118 118 34 6.1 10 2500 3.7
    LPHD613460 60 34 6.1 5 1350 3.7
    LPHD613460 60 34 6.1 15 1200 3.7
    LPHD613496 96 34 6.1 30 1800 3.7
    LPHD614050 50 40 6.1 20 1100 3.7
    LPHD614050 50 40 6.1 20 1000 3.7
    LPHD614050 50 40 6.1 10 1150 3.7
    LPHD6142155 155 42 6.1 8 4400 3.7
    LPHD616078 78 60 6.1 20 2500 3.7
    LPHD6167100 100 67 6.1 5 4500 3.7
    LPHD6175175 175 75 6.1 15 8000 3.7
    LPHD621935 35 19 6.2 20 300 3.7
    LPHD622233 33 22 6.2 20 280 3.7
    LPHD622530 30 25 6.2 15 300 3.7
    LPHD622845 45 28 6.2 25 650 3.7
    LPHD623048 48 30 6.2 1 650 3.7
    LPHD623048 48 30 6.2 15 700 3.7
    LPHD623048 48 30 6.2 5 900 3.7
    LPHD623060 60 30 6.2 20 850 3.7
    LPHD623060 60 30 6.2 20 900 3.7
    LPHD623370 70 33 6.2 20 1000 3.7
    LPHD623460 60 34 6.2 5 1350 3.7
    LPHD623482 82 34 6.2 20 1500 3.7
    LPHD623496 96 34 6.2 30 1800 3.7
    LPHD623562 62 35 6.2 35 1000 3.7
    LPHD623562 62 35 6.2 30 1000 3.7
    LPHD6236128 128 36 6.2 20 2400 3.7
    LPHD623758 58 37 6.2 1 1500 3.7
    LPHD6240150 150 40 6.2 1 4400 3.7
    LPHD624172 72 41 6.2 1 1600 3.7
    LPHD6242126 126 42 6.2 30 2700 3.7
    LPHD624358 58 43 6.2 20 1000 3.7
    LPHD624590 90 45 6.2 1 3000 3.7
    LPHD6248150 150 48 6.2 20 4000 3.7
    LPHD625094 94 50 6.2 1 3700 3.7
    LPHD626078 78 60 6.2 20 2500 3.7
    LPHD626474 74 64 6.2 20 2000 3.7
    LPHD626496 96 64 6.2 20 2800 3.7
    LPHD6265135 135 65 6.2 1 5500 3.7
    LPHD6265135 135 65 6.2 20 4000 3.7
    LPHD626590 90 65 6.2 1 4300 3.7
    LPHD632660 60 26 6.3 20 750 3.7
    LPHD632845 45 28 6.3 30 650 3.7
    LPHD633048 48 30 6.3 15 650 3.7
    LPHD633496 96 34 6.3 25 1800 3.7
    LPHD633562 62 35 6.3 25 1000 3.7
    LPHD633562 62 35 6.3 35 1000 3.7
    LPHD633562 62 35 6.3 20 1000 3.7
    LPHD6342126 126 42 6.3 20 3000 3.7
    LPHD634285 85 42 6.3 8 2600 3.7
    LPHD634358 58 43 6.3 5 1500 3.7
    LPHD6365132 132 65 6.3 1 5000 3.7
    LPHD6365132 132 65 6.3 1 5000 3.7
    LPHD6410100 100 10 6.4 1 5500 3.7
    LPHD641996 96 19 6.4 15 1100 3.7
    LPHD642464 64 24 6.4 15 830 3.7
    LPHD642464 64 24 6.4 15 900 3.7
    LPHD642464 64 24 6.4 10 850 3.7
    LPHD643060 60 30 6.4 25 1000 3.7
    LPHD643060 60 30 6.4 25 850 3.7
    LPHD643126 26 31 6.4 15 430 3.7
    LPHD643476 76 34 6.4 20 1400 3.7
    LPHD6438115 115 38 6.4 30 2700 3.7
    LPHD6442126 126 42 6.4 20 3200 3.7
    LPHD6442126 126 42 6.4 20 3100 3.7
    LPHD6442126 126 42 6.4 30 2800 3.7
    LPHD6442126 126 42 6.4 15 3300 3.7
    LPHD644295 95 42 6.4 5 3000 3.7
    LPHD6443128 128 43 6.4 20 3100 3.7
    LPHD6445150 150 45 6.4 15 4500 3.7
    LPHD6446143 143 46 6.4 20 3800 3.7
    LPHD645652 52 56 6.4 5 1900 3.7
    LPHD6465132 132 65 6.4 5 4000 3.7
    LPHD6465132 132 65 6.4 20 4000 3.7
    LPHD6498220 220 98 6.4 5 15500 3.7
    LPHD651640 40 16 6.5 15 280 3.7
    LPHD651723 23 17 6.5 15 150 3.7
    LPHD651726 26 17 6.5 15 180 3.7
    LPHD651775 75 17 6.5 10 800 3.7
    LPHD652030 30 20 6.5 15 250 3.7
    LPHD652030 30 20 6.5 15 270 3.7
    LPHD652138 38 21 6.5 10 400 3.7
    LPHD652892 92 28 6.5 20 1150 3.7
    LPHD6530125 125 30 6.5 1 8000 3.7
    LPHD653040 40 30 6.5 15 650 3.7
    LPHD653048 48 30 6.5 10 800 3.7
    LPHD653060 60 30 6.5 15 1000 3.7
    LPHD6531122 122 31 6.5 5 3000 3.7
    LPHD653496 96 34 6.5 8 2150 3.7
    LPHD653562 62 35 6.5 30 1000 3.7
    LPHD6536102 102 36 6.5 5 2750 3.7
    LPHD6536102 102 36 6.5 5 2950 3.7
    LPHD6542126 126 42 6.5 30 3200 3.7
    LPHD6542150 150 42 6.5 8 4650 3.7
    LPHD6543128 128 43 6.5 20 3200 3.7
    LPHD6543128 128 43 6.5 1 4000 3.7
    LPHD654380 80 43 6.5 1 1850 3.7
    LPHD6544100 100 44 6.5 20 2700 3.7
    LPHD6545150 150 45 6.5 20 4000 3.7
    LPHD655446 46 54 6.5 5 1800 3.7
    LPHD6565132 132 65 6.5 1 5500 3.7
    LPHD6570135 135 70 6.5 20 6000 3.7
    LPHD657068 68 70 6.5 20 2000 3.7
    LPHD657092 92 70 6.5 20 2950 3.7
    LPHD657096 96 70 6.5 1 5450 3.7
    LPHD6572200 200 72 6.5 10 10000 3.7
    LPHD6575106 106 75 6.5 20 4700 3.7
    LPHD6578156 156 78 6.5 25 6000 3.7
    LPHD6588106 106 88 6.5 1 7500 3.7
    LPHD6592162 162 92 6.5 1 12000 3.7
    LPHD661340 40 13 6.6 5 230 3.7
    LPHD661654 54 16 6.6 25 450 3.7
    LPHD662689 89 26 6.6 15 1500 3.7
    LPHD663060 60 30 6.6 15 1000 3.7
    LPHD663496 96 34 6.6 20 1800 3.7
    LPHD663562 62 35 6.6 15 1250 3.7
    LPHD6642126 126 42 6.6 25 3550 3.7
    LPHD6642126 126 42 6.6 20 3200 3.7
    LPHD6642126 126 42 6.6 20 3300 3.7
    LPHD6642126 126 42 6.6 30 3300 3.7
    LPHD6642126 126 42 6.6 30 3400 3.7
    LPHD6642126 126 42 6.6 20 3500 3.7
    LPHD6643128 128 43 6.6 35 3000 3.7
    LPHD6643128 128 43 6.6 25 3000 3.7
    LPHD6644100 100 44 6.6 20 2700 3.7
    LPHD6645135 135 45 6.6 1 5000 3.7
    LPHD6646143 143 46 6.6 25 4200 3.7
    LPHD6649140 140 49 6.6 10 5000 3.7
    LPHD6651143 143 51 6.6 35 4400 3.7
    LPHD667092 92 70 6.6 1 5000 3.7
    LPHD6678156 156 78 6.6 25 6000 3.7
    LPHD672342 42 23 6.7 30 500 3.7
    LPHD673388 88 33 6.7 15 1950 3.7
    LPHD673388 88 33 6.7 15 1800 3.7
    LPHD6734122 122 34 6.7 10 2800 3.7
    LPHD673496 96 34 6.7 15 2100 3.7
    LPHD6742126 126 42 6.7 20 3300 3.7
    LPHD6743128 128 43 6.7 35 3000 3.7
    LPHD674360 60 43 6.7 8 1700 3.7
    LPHD6744115 115 44 6.7 20 3300 3.7
    LPHD674752 52 47 6.7 15 1700 3.7
    LPHD6750115 115 50 6.7 5 5000 3.7
    LPHD675365 65 53 6.7 1 2900 3.7
    LPHD6756104 104 56 6.7 5 5100 3.7
    LPHD6759145 145 59 6.7 1 7500 3.7
    LPHD676164 64 61 6.7 5 3000 3.7
    LPHD6770135 135 70 6.7 20 6000 3.7
    LPHD6775106 106 75 6.7 1 4500 3.7
    LPHD6810100 100 10 6.8 1 8000 3.7
    LPHD681955 55 19 6.8 15 550 3.7
    LPHD682025 25 20 6.8 15 200 3.7
    LPHD682030 30 20 6.8 15 280 3.7
    LPHD6831122 122 31 6.8 5 3000 3.7
    LPHD683476 76 34 6.8 20 1650 3.7
    LPHD683496 96 34 6.8 20 1800 3.7
    LPHD683496 96 34 6.8 10 1800 3.7
    LPHD683496 96 34 6.8 30 1800 3.7
    LPHD683496 96 34 6.8 25 1800 3.7
    LPHD683562 62 35 6.8 1 1650 3.7
    LPHD683562 62 35 6.8 8 1550 3.7
    LPHD683562 62 35 6.8 20 1200 3.7
    LPHD683562 62 35 6.8 20 1300 3.7
    LPHD683562 62 35 6.8 15 1400 3.7
    LPHD683658 58 36 6.8 15 1400 3.7
    LPHD6842125 125 42 6.8 20 3000 3.7
    LPHD6842126 126 42 6.8 20 3150 3.7
    LPHD6843128 128 43 6.8 15 3800 3.7
    LPHD684358 58 43 6.8 30 1000 3.7
    LPHD6845135 135 45 6.8 8 4800 3.7
    LPHD6845180 180 45 6.8 1 5800 3.7
    LPHD6846143 143 46 6.8 20 4200 3.7
    LPHD684764 64 47 6.8 1 2500 3.7
    LPHD6849135 135 49 6.8 30 4400 3.7
    LPHD6850115 115 50 6.8 25 2800 3.7
    LPHD6851143 143 51 6.8 10 5450 3.7
    LPHD686164 64 61 6.8 1 3100 3.7
    LPHD692437 37 24 6.9 30 450 3.7
    LPHD692845 45 28 6.9 25 730 3.7
    LPHD692978 78 29 6.9 30 1200 3.7
    LPHD693388 88 33 6.9 5 2200 3.7
    LPHD693450 50 34 6.9 15 1000 3.7
    LPHD693496 96 34 6.9 5 2600 3.7
    LPHD693496 96 34 6.9 30 2100 3.7
    LPHD693562 62 35 6.9 15 1250 3.7
    LPHD693562 62 35 6.9 25 1300 3.7
    LPHD693562 62 35 6.9 15 1250 3.7
    LPHD693658 58 36 6.9 15 1400 3.7
    LPHD6938110 110 38 6.9 20 2750 3.7
    LPHD6942126 126 42 6.9 5 4500 3.7
    LPHD6943143 143 43 6.9 20 4200 3.7
    LPHD694358 58 43 6.9 20 1500 3.7
    LPHD6945135 135 45 6.9 8 4800 3.7
    LPHD6945150 150 45 6.9 20 4000 3.7
    LPHD6945150 150 45 6.9 30 4600 3.7
    LPHD6945180 180 45 6.9 20 5500 3.7
    LPHD6949135 135 49 6.9 1 6050 3.7
    LPHD6949135 135 49 6.9 20 4500 3.7
    LPHD695490 90 54 6.9 1 4000 3.7
    LPHD695572 72 55 6.9 5 3200 3.7
    LPHD696195 95 61 6.9 1 5000 3.7
    LPHD6965132 132 65 6.9 25 4300 3.7
    LPHD696586 86 65 6.9 25 3700 3.7



    Alta Scarico C-rating Batteria Litio Polimeri
    spessore 7.0mm to 7.9mm, 350mAh to 22000mAh, 15C to 40C

    -
    Modello lunghezza
    (mm)
    Altezza
    (mm)
    spessore
    (mm)
    C-rating capacità
    (mAh)
    tensione
    (V)
    LPHD701855 55 18 7.0 15 600 3.7
    LPHD701988 88 19 7.0 15 1050 3.7
    LPHD701996 96 19 7.0 15 1100 3.7
    LPHD702035 35 20 7.0 15 350 3.7
    LPHD702530 30 25 7.0 5 400 3.7
    LPHD702689 89 26 7.0 15 1450 3.7
    LPHD7030100 100 30 7.0 20 1750 3.7
    LPHD703040 40 30 7.0 20 700 3.7
    LPHD703048 48 30 7.0 15 800 3.7
    LPHD703048 48 30 7.0 20 800 3.7
    LPHD703060 60 30 7.0 20 1000 3.7
    LPHD703082 82 30 7.0 10 1650 3.7
    LPHD703142 42 31 7.0 20 500 3.7
    LPHD703351 51 33 7.0 10 1100 3.7
    LPHD7034106 106 34 7.0 20 2200 3.7
    LPHD7034106 106 34 7.0 30 2200 3.7
    LPHD703482 82 34 7.0 20 1800 3.7
    LPHD703482 82 34 7.0 30 1800 3.7
    LPHD703496 96 34 7.0 35 2000 3.7
    LPHD703496 96 34 7.0 35 1800 3.7
    LPHD703496 96 34 7.0 5 2600 3.7
    LPHD703496 96 34 7.0 30 2100 3.7
    LPHD703562 62 35 7.0 25 1200 3.7
    LPHD703562 62 35 7.0 15 1300 3.7
    LPHD703562 62 35 7.0 20 1200 3.7
    LPHD703562 62 35 7.0 30 1250 3.7
    LPHD703562 62 35 7.0 30 1300 3.7
    LPHD703562 62 35 7.0 8 1550 3.7
    LPHD703768 68 37 7.0 20 1500 3.7
    LPHD7038110 110 38 7.0 20 2500 3.7
    LPHD704172 72 41 7.0 5 2350 3.7
    LPHD7042126 126 42 7.0 30 3100 3.7
    LPHD7042126 126 42 7.0 15 3900 3.7
    LPHD7042126 126 42 7.0 20 3700 3.7
    LPHD7042126 126 42 7.0 15 3700 3.7
    LPHD7043128 128 43 7.0 20 3200 3.7
    LPHD704360 60 43 7.0 20 1500 3.7
    LPHD704590 90 45 7.0 1 3600 3.7
    LPHD7046143 143 46 7.0 20 4500 3.7
    LPHD7049135 135 49 7.0 1 5000 3.7
    LPHD7049135 135 49 7.0 35 4000 3.7
    LPHD705582 82 55 7.0 1 2850 3.7
    LPHD7058150 150 58 7.0 5 7000 3.7
    LPHD7063124 124 63 7.0 1 5000 3.7
    LPHD7067220 220 67 7.0 1 10000 3.7
    LPHD7070135 135 70 7.0 20 5000 3.7
    LPHD7070170 170 70 7.0 1 11000 3.7
    LPHD708273 73 82 7.0 10 4100 3.7
    LPHD708278 78 82 7.0 5 5100 3.7
    LPHD708278 78 82 7.0 5 5000 3.7
    LPHD7088106 106 88 7.0 1 7500 3.7
    LPHD713048 48 30 7.1 20 850 3.7
    LPHD713085 85 30 7.1 30 1600 3.7
    LPHD713351 51 33 7.1 1 1250 3.7
    LPHD713482 82 34 7.1 30 1800 3.7
    LPHD713496 96 34 7.1 5 2600 3.7
    LPHD713496 96 34 7.1 35 1800 3.7
    LPHD713498 98 34 7.1 5 2800 3.7
    LPHD713498 98 34 7.1 5 3050 3.7
    LPHD713562 62 35 7.1 30 1300 3.7
    LPHD713562 62 35 7.1 35 1300 3.7
    LPHD7138115 115 38 7.1 20 2700 3.7
    LPHD7142126 126 42 7.1 20 3800 3.7
    LPHD7143128 128 43 7.1 20 4000 3.7
    LPHD714358 58 43 7.1 20 1650 3.7
    LPHD7145135 135 45 7.1 5 5400 3.7
    LPHD714590 90 45 7.1 5 3600 3.7
    LPHD7156104 104 56 7.1 5 5100 3.7
    LPHD7170135 135 70 7.1 20 6000 3.7
    LPHD7172200 200 72 7.1 10 11000 3.7
    LPHD721662 62 16 7.2 15 600 3.7
    LPHD721723 23 17 7.2 15 180 3.7
    LPHD722035 35 20 7.2 20 350 3.7
    LPHD722848 48 28 7.2 15 850 3.7
    LPHD723040 40 30 7.2 20 650 3.7
    LPHD723048 48 30 7.2 35 800 3.7
    LPHD723048 48 30 7.2 30 850 3.7
    LPHD723082 82 30 7.2 15 1600 3.7
    LPHD723082 82 30 7.2 5 2050 3.7
    LPHD7234106 106 34 7.2 5 2950 3.7
    LPHD7234122 122 34 7.2 20 2200 3.7
    LPHD723460 60 34 7.2 15 1400 3.7
    LPHD723496 96 34 7.2 30 2200 3.7
    LPHD723496 96 34 7.2 30 1800 3.7
    LPHD723562 62 35 7.2 20 1300 3.7
    LPHD7236128 128 36 7.2 20 3000 3.7
    LPHD7242126 126 42 7.2 30 3500 3.7
    LPHD7242126 126 42 7.2 30 3700 3.7
    LPHD7243128 128 43 7.2 20 3400 3.7
    LPHD724358 58 43 7.2 20 1500 3.7
    LPHD724358 58 43 7.2 20 1600 3.7
    LPHD724358 58 43 7.2 10 2000 3.7
    LPHD724358 58 43 7.2 15 1850 3.7
    LPHD7244115 115 44 7.2 5 4600 3.7
    LPHD7245180 180 45 7.2 25 5600 3.7
    LPHD7246143 143 46 7.2 25 4200 3.7
    LPHD7249135 135 49 7.2 1 6300 3.7
    LPHD7249135 135 49 7.2 1 6000 3.7
    LPHD7250115 115 50 7.2 1 5000 3.7
    LPHD7255145 145 55 7.2 1 5000 3.7
    LPHD7259156 156 59 7.2 1 5400 3.7
    LPHD7270156 156 70 7.2 5 9000 3.7
    LPHD732437 37 24 7.3 15 520 3.7
    LPHD732464 64 24 7.3 20 1000 3.7
    LPHD733048 48 30 7.3 20 800 3.7
    LPHD7334122 122 34 7.3 15 3000 3.7
    LPHD733450 50 34 7.3 15 1000 3.7
    LPHD733496 96 34 7.3 5 2950 3.7
    LPHD733496 96 34 7.3 20 2200 3.7
    LPHD733496 96 34 7.3 5 2600 3.7
    LPHD733562 62 35 7.3 35 1300 3.7
    LPHD733562 62 35 7.3 10 1450 3.7
    LPHD7336128 128 36 7.3 15 3700 3.7
    LPHD7342126 126 42 7.3 15 4100 3.7
    LPHD7342126 126 42 7.3 35 3300 3.7
    LPHD734358 58 43 7.3 10 1800 3.7
    LPHD7344115 115 44 7.3 30 3200 3.7
    LPHD7345135 135 45 7.3 5 5400 3.7
    LPHD7345135 135 45 7.3 5 5800 3.7
    LPHD7345150 150 45 7.3 20 4500 3.7
    LPHD7349135 135 49 7.3 30 4400 3.7
    LPHD7349135 135 49 7.3 20 4400 3.7
    LPHD7351175 175 51 7.3 5 8000 3.7
    LPHD7356104 104 56 7.3 5 5200 3.7
    LPHD7365132 132 65 7.3 1 5000 3.7
    LPHD7385155 155 85 7.3 15 10000 3.7
    LPHD741730 30 17 7.4 20 260 3.7
    LPHD741955 55 19 7.4 20 630 3.7
    LPHD742437 37 24 7.4 10 550 3.7
    LPHD742437 37 24 7.4 15 520 3.7
    LPHD743048 48 30 7.4 20 650 3.7
    LPHD743060 60 30 7.4 15 1200 3.7
    LPHD743085 85 30 7.4 20 1600 3.7
    LPHD743085 85 30 7.4 30 1600 3.7
    LPHD743085 85 30 7.4 5 2000 3.7
    LPHD743496 96 34 7.4 20 2100 3.7
    LPHD743496 96 34 7.4 10 1800 3.7
    LPHD743496 96 34 7.4 30 2300 3.7
    LPHD743496 96 34 7.4 25 2200 3.7
    LPHD743562 62 35 7.4 10 1100 3.7
    LPHD7436128 128 36 7.4 20 3000 3.7
    LPHD7439100 100 39 7.4 8 3100 3.7
    LPHD7442126 126 42 7.4 20 3650 3.7
    LPHD7443128 128 43 7.4 20 3600 3.7
    LPHD7445135 135 45 7.4 25 4500 3.7
    LPHD7445135 135 45 7.4 25 3000 3.7
    LPHD7445180 180 45 7.4 30 5000 3.7
    LPHD7446143 143 46 7.4 20 5000 3.7
    LPHD7446143 143 46 7.4 20 4400 3.7
    LPHD744985 85 49 7.4 1 3300 3.7
    LPHD745582 82 55 7.4 20 3200 3.7
    LPHD746586 86 65 7.4 25 3700 3.7
    LPHD7470175 175 70 7.4 10 10000 3.7
    LPHD751935 35 19 7.5 15 380 3.7
    LPHD751955 55 19 7.5 20 600 3.7
    LPHD753048 48 30 7.5 35 800 3.7
    LPHD753048 48 30 7.5 5 1100 3.7
    LPHD753060 60 30 7.5 10 1300 3.7
    LPHD753085 85 30 7.5 15 1750 3.7
    LPHD753085 85 30 7.5 5 2000 3.7
    LPHD753142 42 31 7.5 20 500 3.7
    LPHD753450 50 34 7.5 1 1350 3.7
    LPHD753476 76 34 7.5 20 1600 3.7
    LPHD753562 62 35 7.5 15 1450 3.7
    LPHD753562 62 35 7.5 20 1300 3.7
    LPHD753562 62 35 7.5 15 1550 3.7
    LPHD7536128 128 36 7.5 20 3000 3.7
    LPHD7538110 110 38 7.5 20 2700 3.7
    LPHD7542126 126 42 7.5 8 4500 3.7
    LPHD7542126 126 42 7.5 20 3100 3.7
    LPHD7542126 126 42 7.5 30 3300 3.7
    LPHD7542126 126 42 7.5 5 4800 3.7
    LPHD7543128 128 43 7.5 20 3800 3.7
    LPHD754380 80 43 7.5 5 3400 3.7
    LPHD7544100 100 44 7.5 1 3350 3.7
    LPHD7545135 135 45 7.5 5 5000 3.7
    LPHD7545135 135 45 7.5 20 4000 3.7
    LPHD7545150 150 45 7.5 20 4700 3.7
    LPHD7545150 150 45 7.5 30 4580 3.7
    LPHD755180 80 51 7.5 5 2500 3.7
    LPHD755180 80 51 7.5 5 3500 3.7
    LPHD755490 90 54 7.5 25 3100 3.7
    LPHD7558150 150 58 7.5 5 7650 3.7
    LPHD7564159 159 64 7.5 20 7500 3.7
    LPHD7565135 135 65 7.5 1 5000 3.7
    LPHD7570135 135 70 7.5 1 7700 3.7
    LPHD757068 68 70 7.5 1 2800 3.7
    LPHD7585186 186 85 7.5 15 12500 3.7
    LPHD762035 35 20 7.6 10 400 3.7
    LPHD7630100 100 30 7.6 5 2500 3.7
    LPHD763048 48 30 7.6 1 1100 3.7
    LPHD763048 48 30 7.6 25 800 3.7
    LPHD763048 48 30 7.6 35 800 3.7
    LPHD763048 48 30 7.6 20 850 3.7
    LPHD763048 48 30 7.6 20 800 3.7
    LPHD763048 48 30 7.6 30 800 3.7
    LPHD763048 48 30 7.6 40 800 3.7
    LPHD763048 48 30 7.6 30 850 3.7
    LPHD7634106 106 34 7.6 30 2200 3.7
    LPHD7634106 106 34 7.6 20 2400 3.7
    LPHD763482 82 34 7.6 30 1800 3.7
    LPHD763496 96 34 7.6 20 2100 3.7
    LPHD763562 62 35 7.6 20 1100 3.7
    LPHD763562 62 35 7.6 35 1300 3.7
    LPHD7642126 126 42 7.6 20 3600 3.7
    LPHD7642126 126 42 7.6 20 3700 3.7
    LPHD7642126 126 42 7.6 30 4000 3.7
    LPHD7642126 126 42 7.6 15 4500 3.7
    LPHD7642126 126 42 7.6 20 3100 3.7
    LPHD7643128 128 43 7.6 20 3600 3.7
    LPHD764380 80 43 7.6 5 3150 3.7
    LPHD7645135 135 45 7.6 25 4000 3.7
    LPHD7645150 150 45 7.6 30 5000 3.7
    LPHD7646143 143 46 7.6 30 5000 3.7
    LPHD7649135 135 49 7.6 20 5100 3.7
    LPHD7658150 150 58 7.6 15 7000 3.7
    LPHD7659156 156 59 7.6 1 6000 3.7
    LPHD7660119 119 60 7.6 5 6800 3.7
    LPHD7664155 155 64 7.6 15 8000 3.7
    LPHD7665132 132 65 7.6 1 6000 3.7
    LPHD766689 89 66 7.6 5 5600 3.7
    LPHD7670135 135 70 7.6 5 8100 3.7
    LPHD7670175 175 70 7.6 10 10000 3.7
    LPHD7672196 196 72 7.6 5 12500 3.7
    LPHD7675106 106 75 7.6 1 7800 3.7
    LPHD7685186 186 85 7.6 15 12500 3.7
    LPHD773048 48 30 7.7 35 800 3.7
    LPHD773048 48 30 7.7 1 1250 3.7
    LPHD773294 94 32 7.7 20 2300 3.7
    LPHD7734100 100 34 7.7 15 2500 3.7
    LPHD773482 82 34 7.7 30 1800 3.7
    LPHD773562 62 35 7.7 35 1300 3.7
    LPHD773562 62 35 7.7 30 1300 3.7
    LPHD7742126 126 42 7.7 30 4000 3.7
    LPHD7743135 135 43 7.7 20 4000 3.7
    LPHD7744175 175 44 7.7 1 7500 3.7
    LPHD7744175 175 44 7.7 15 5900 3.7
    LPHD7744175 175 44 7.7 20 5600 3.7
    LPHD774590 90 45 7.7 5 3600 3.7
    LPHD7746143 143 46 7.7 20 5200 3.7
    LPHD7748150 150 48 7.7 15 6000 3.7
    LPHD775180 80 51 7.7 1 3000 3.7
    LPHD7770170 170 70 7.7 10 10000 3.7
    LPHD7770175 175 70 7.7 10 10000 3.7
    LPHD7785186 186 85 7.7 15 12500 3.7
    LPHD782030 30 20 7.8 15 350 3.7
    LPHD783048 48 30 7.8 5 1100 3.7
    LPHD783048 48 30 7.8 10 1000 3.7
    LPHD783082 82 30 7.8 5 2250 3.7
    LPHD783082 82 30 7.8 20 1550 3.7
    LPHD783082 82 30 7.8 20 1650 3.7
    LPHD783085 85 30 7.8 25 1600 3.7
    LPHD783476 76 34 7.8 15 2000 3.7
    LPHD783496 96 34 7.8 20 1800 3.7
    LPHD783496 96 34 7.8 20 2100 3.7
    LPHD783496 96 34 7.8 15 2400 3.7
    LPHD783496 96 34 7.8 20 2200 3.7
    LPHD783496 96 34 7.8 25 2400 3.7
    LPHD783542 42 35 7.8 10 1000 3.7
    LPHD783562 62 35 7.8 25 1300 3.7
    LPHD783562 62 35 7.8 20 1400 3.7
    LPHD783562 62 35 7.8 30 1500 3.7
    LPHD783562 62 35 7.8 30 1300 3.7
    LPHD783562 62 35 7.8 35 1450 3.7
    LPHD784078 78 40 7.8 8 2700 3.7
    LPHD7842126 126 42 7.8 20 3700 3.7
    LPHD784280 80 42 7.8 5 3150 3.7
    LPHD7843128 128 43 7.8 1 4400 3.7
    LPHD7843128 128 43 7.8 25 3600 3.7
    LPHD784380 80 43 7.8 8 2900 3.7
    LPHD784380 80 43 7.8 5 3100 3.7
    LPHD784380 80 43 7.8 20 2300 3.7
    LPHD784380 80 43 7.8 20 2550 3.7
    LPHD7845119 119 45 7.8 8 4900 3.7
    LPHD7845135 135 45 7.8 30 4400 3.7
    LPHD7845180 180 45 7.8 20 5500 3.7
    LPHD7846143 143 46 7.8 25 4600 3.7
    LPHD7849135 135 49 7.8 40 4000 3.7
    LPHD7849135 135 49 7.8 30 4400 3.7
    LPHD7858150 150 58 7.8 15 7000 3.7
    LPHD785998 98 59 7.8 25 3300 3.7
    LPHD7864155 155 64 7.8 15 8000 3.7
    LPHD7870170 170 70 7.8 10 10000 3.7
    LPHD7870170 170 70 7.8 1 9500 3.7
    LPHD7870192 192 70 7.8 1 10000 3.7
    LPHD787068 68 70 7.8 1 3000 3.7
    LPHD7885186 186 85 7.8 15 12500 3.7
    LPHD7898225 225 98 7.8 5 21000 3.7
    LPHD7898225 225 98 7.8 5 22000 3.7
    LPHD7934122 122 34 7.9 20 3000 3.7
    LPHD793476 76 34 7.9 15 1950 3.7
    LPHD793496 96 34 7.9 25 2100 3.7
    LPHD793496 96 34 7.9 20 2200 3.7
    LPHD793562 62 35 7.9 40 1300 3.7
    LPHD7942126 126 42 7.9 20 3800 3.7
    LPHD7943128 128 43 7.9 15 4200 3.7
    LPHD7943128 128 43 7.9 35 3500 3.7
    LPHD7944175 175 44 7.9 20 5600 3.7
    LPHD7945119 119 45 7.9 8 4900 3.7
    LPHD7945150 150 45 7.9 20 5000 3.7



    Alta Scarico C-rating Batteria Litio Polimeri
    spessore 8.0mm to 8.9mm, 350mAh to 21000mAh, 1C to 35C

    Modello lunghezza
    (mm)
    Altezza
    (mm)
    spessore
    (mm)
    C-rating capacità
    (mAh)
    tensione
    (V)
    LPHD802030 30 20 8.0 15 350 3.7
    LPHD802437 37 24 8.0 15 600 3.7
    LPHD803060 60 30 8.0 10 1300 3.7
    LPHD803060 60 30 8.0 30 1200 3.7
    LPHD803082 82 30 8.0 20 1650 3.7
    LPHD803082 82 30 8.0 30 1800 3.7
    LPHD803082 82 30 8.0 30 1500 3.7
    LPHD803082 82 30 8.0 1 2300 3.7
    LPHD803085 85 30 8.0 5 2400 3.7
    LPHD8034122 122 34 8.0 20 2500 3.7
    LPHD803496 96 34 8.0 20 2300 3.7
    LPHD803562 62 35 8.0 20 1500 3.7
    LPHD8036128 128 36 8.0 20 2500 3.7
    LPHD804078 78 40 8.0 8 2700 3.7
    LPHD8041117 117 41 8.0 5 4500 3.7
    LPHD804172 72 41 8.0 1 2050 3.7
    LPHD8042126 126 42 8.0 25 4200 3.7
    LPHD8042126 126 42 8.0 15 4200 3.7
    LPHD8042126 126 42 8.0 20 3850 3.7
    LPHD804240 40 42 8.0 8 1300 3.7
    LPHD8043128 128 43 8.0 35 3500 3.7
    LPHD8043128 128 43 8.0 20 4000 3.7
    LPHD804380 80 43 8.0 20 1900 3.7
    LPHD8044175 175 44 8.0 20 5900 3.7
    LPHD8045119 119 45 8.0 8 5100 3.7
    LPHD8045119 119 45 8.0 5 5200 3.7
    LPHD8045135 135 45 8.0 20 4400 3.7
    LPHD8045150 150 45 8.0 25 5500 3.7
    LPHD8045180 180 45 8.0 25 5500 3.7
    LPHD804575 75 45 8.0 20 1900 3.7
    LPHD805686 86 56 8.0 5 4500 3.7
    LPHD8064155 155 64 8.0 1 10000 3.7
    LPHD8065132 132 65 8.0 1 6500 3.7
    LPHD8067100 100 67 8.0 20 4100 3.7
    LPHD8067220 220 67 8.0 1 10000 3.7
    LPHD8070135 135 70 8.0 1 10000 3.7
    LPHD8070170 170 70 8.0 1 8000 3.7
    LPHD8070170 170 70 8.0 5 12600 3.7
    LPHD8070170 170 70 8.0 10 10000 3.7
    LPHD8070170 170 70 8.0 1 12600 3.7
    LPHD8072196 196 72 8.0 1 10000 3.7
    LPHD8083145 145 83 8.0 8 10500 3.7
    LPHD8098225 225 98 8.0 5 21000 3.7
    LPHD812530 30 25 8.1 15 450 3.7
    LPHD8134122 122 34 8.1 20 2500 3.7
    LPHD813496 96 34 8.1 20 2300 3.7
    LPHD8142126 126 42 8.1 20 4000 3.7
    LPHD8144107 107 44 8.1 5 4800 3.7
    LPHD8145119 119 45 8.1 5 5200 3.7
    LPHD8148150 150 48 8.1 15 6000 3.7
    LPHD8164155 155 64 8.1 20 8000 3.7
    LPHD8164159 159 64 8.1 20 8000 3.7
    LPHD821840 40 18 8.2 1 450 3.7
    LPHD821996 96 19 8.2 15 1350 3.7
    LPHD822530 30 25 8.2 15 450 3.7
    LPHD822595 95 25 8.2 1 1500 3.7
    LPHD822595 95 25 8.2 5 2100 3.7
    LPHD823082 82 30 8.2 15 1800 3.7
    LPHD823082 82 30 8.2 20 1800 3.7
    LPHD823362 62 33 8.2 5 1800 3.7
    LPHD8234100 100 34 8.2 20 2500 3.7
    LPHD8234106 106 34 8.2 20 2600 3.7
    LPHD8234122 122 34 8.2 20 2600 3.7
    LPHD823496 96 34 8.2 20 2400 3.7
    LPHD823496 96 34 8.2 10 2100 3.7
    LPHD823496 96 34 8.2 30 2300 3.7
    LPHD823496 96 34 8.2 25 2200 3.7
    LPHD823562 62 35 8.2 25 1600 3.7
    LPHD823990 90 39 8.2 1 3700 3.7
    LPHD8242126 126 42 8.2 5 5300 3.7
    LPHD8242126 126 42 8.2 20 4000 3.7
    LPHD8242126 126 42 8.2 30 4300 3.7
    LPHD8242126 126 42 8.2 30 3800 3.7
    LPHD8242126 126 42 8.2 20 4500 3.7
    LPHD824240 40 42 8.2 10 1300 3.7
    LPHD8243128 128 43 8.2 20 4000 3.7
    LPHD824380 80 43 8.2 5 3400 3.7
    LPHD824396 96 43 8.2 5 3900 3.7
    LPHD8244175 175 44 8.2 20 5900 3.7
    LPHD8245135 135 45 8.2 30 4400 3.7
    LPHD8245135 135 45 8.2 20 5100 3.7
    LPHD8245135 135 45 8.2 25 4400 3.7
    LPHD8245150 150 45 8.2 20 5000 3.7
    LPHD8245150 150 45 8.2 20 5500 3.7
    LPHD8245150 150 45 8.2 20 5300 3.7
    LPHD8248150 150 48 8.2 15 6000 3.7
    LPHD8249135 135 49 8.2 8 5800 3.7
    LPHD824992 92 49 8.2 25 2500 3.7
    LPHD8255270 270 55 8.2 1 17300 3.7
    LPHD8264155 155 64 8.2 20 8000 3.7
    LPHD8265135 135 65 8.2 1 9100 3.7
    LPHD8270170 170 70 8.2 1 10000 3.7
    LPHD8272196 196 72 8.2 1 12500 3.7
    LPHD8285155 155 85 8.2 10 12000 3.7
    LPHD8298125 125 98 8.2 15 10500 3.7
    LPHD833048 48 30 8.3 15 1000 3.7
    LPHD8334122 122 34 8.3 10 3500 3.7
    LPHD833496 96 34 8.3 35 2200 3.7
    LPHD833496 96 34 8.3 30 2200 3.7
    LPHD833496 96 34 8.3 5 3200 3.7
    LPHD834240 40 42 8.3 10 1300 3.7
    LPHD8343128 128 43 8.3 1 5000 3.7
    LPHD8345150 150 45 8.3 25 5000 3.7
    LPHD8345150 150 45 8.3 20 5100 3.7
    LPHD8345150 150 45 8.3 30 5200 3.7
    LPHD8346143 143 46 8.3 20 5000 3.7
    LPHD8355270 270 55 8.3 5 15000 3.7
    LPHD835686 86 56 8.3 1 5200 3.7
    LPHD8358150 150 58 8.3 15 7500 3.7
    LPHD8363124 124 63 8.3 15 7500 3.7
    LPHD8363135 135 63 8.3 15 7000 3.7
    LPHD8364155 155 64 8.3 20 8000 3.7
    LPHD8365132 132 65 8.3 1 8000 3.7
    LPHD8365132 132 65 8.3 1 8500 3.7
    LPHD8365135 135 65 8.3 1 8500 3.7
    LPHD8370175 175 70 8.3 10 12000 3.7
    LPHD842978 78 29 8.4 30 1500 3.7
    LPHD843082 82 30 8.4 20 1800 3.7
    LPHD843085 85 30 8.4 5 2400 3.7
    LPHD8432115 115 32 8.4 10 3300 3.7
    LPHD8434106 106 34 8.4 20 2700 3.7
    LPHD843496 96 34 8.4 35 2200 3.7
    LPHD843562 62 35 8.4 30 1600 3.7
    LPHD843562 62 35 8.4 20 1600 3.7
    LPHD844295 95 42 8.4 1 4200 3.7
    LPHD8443128 128 43 8.4 20 4200 3.7
    LPHD8443128 128 43 8.4 8 5050 3.7
    LPHD8445150 150 45 8.4 25 5000 3.7
    LPHD8463124 124 63 8.4 15 7500 3.7
    LPHD8464204 204 64 8.4 5 13800 3.7
    LPHD8465132 132 65 8.4 1 6000 3.7
    LPHD846586 86 65 8.4 1 6000 3.7
    LPHD8467105 105 67 8.4 25 4000 3.7
    LPHD8467220 220 67 8.4 1 16000 3.7
    LPHD8498220 220 98 8.4 5 21000 3.7
    LPHD852845 45 28 8.5 1 1100 3.7
    LPHD8534106 106 34 8.5 20 2600 3.7
    LPHD8534113 113 34 8.5 5 4100 3.7
    LPHD853450 50 34 8.5 1 1500 3.7
    LPHD853496 96 34 8.5 15 2700 3.7
    LPHD853496 96 34 8.5 20 2400 3.7
    LPHD853496 96 34 8.5 20 2700 3.7
    LPHD853562 62 35 8.5 30 1600 3.7
    LPHD8536128 128 36 8.5 20 3800 3.7
    LPHD853861 61 38 8.5 1 2500 3.7
    LPHD854066 66 40 8.5 30 1850 3.7
    LPHD8542121 121 42 8.5 20 3300 3.7
    LPHD8542126 126 42 8.5 25 4200 3.7
    LPHD8542126 126 42 8.5 15 4500 3.7
    LPHD8542126 126 42 8.5 20 4150 3.7
    LPHD8542126 126 42 8.5 15 5200 3.7
    LPHD8542126 126 42 8.5 20 4600 3.7
    LPHD8543128 128 43 8.5 35 3700 3.7
    LPHD8545135 135 45 8.5 25 4000 3.7
    LPHD8545135 135 45 8.5 25 4500 3.7
    LPHD8545150 150 45 8.5 20 5300 3.7
    LPHD8546143 143 46 8.5 20 5100 3.7
    LPHD8548150 150 48 8.5 20 6000 3.7
    LPHD855686 86 56 8.5 1 5500 3.7
    LPHD8559156 156 59 8.5 1 10000 3.7
    LPHD8563124 124 63 8.5 15 7500 3.7
    LPHD8564155 155 64 8.5 1 10000 3.7
    LPHD8564159 159 64 8.5 5 10000 3.7
    LPHD856689 89 66 8.5 5 6300 3.7
    LPHD8578156 156 78 8.5 25 8000 3.7
    LPHD8585187 187 85 8.5 10 15000 3.7
    LPHD8588106 106 88 8.5 5 10000 3.7
    LPHD863048 48 30 8.6 30 1000 3.7
    LPHD863060 60 30 8.6 30 1200 3.7
    LPHD8634122 122 34 8.6 20 2600 3.7
    LPHD863496 96 34 8.6 5 3400 3.7
    LPHD863562 62 35 8.6 30 1550 3.7
    LPHD8636128 128 36 8.6 20 3500 3.7
    LPHD8642124 124 42 8.6 20 4400 3.7
    LPHD8642126 126 42 8.6 15 5000 3.7
    LPHD8642126 126 42 8.6 30 4500 3.7
    LPHD864270 70 42 8.6 15 2500 3.7
    LPHD8643128 128 43 8.6 20 4300 3.7
    LPHD8643128 128 43 8.6 35 4000 3.7
    LPHD8645150 150 45 8.6 30 5000 3.7
    LPHD8645150 150 45 8.6 35 5000 3.7
    LPHD864985 85 49 8.6 5 4400 3.7
    LPHD865998 98 59 8.6 5 5700 3.7
    LPHD8663124 124 63 8.6 15 7500 3.7
    LPHD873085 85 30 8.7 1 2600 3.7
    LPHD873562 62 35 8.7 30 1550 3.7
    LPHD8736128 128 36 8.7 20 3600 3.7
    LPHD8742126 126 42 8.7 35 4000 3.7
    LPHD8743128 128 43 8.7 35 4000 3.7
    LPHD8745135 135 45 8.7 20 5100 3.7
    LPHD8745150 150 45 8.7 35 5000 3.7
    LPHD874985 85 49 8.7 5 4400 3.7
    LPHD875686 86 56 8.7 20 4000 3.7
    LPHD875998 98 59 8.7 10 5600 3.7
    LPHD8763124 124 63 8.7 15 7500 3.7
    LPHD8767100 100 67 8.7 1 5000 3.7
    LPHD8770175 175 70 8.7 5 13800 3.7
    LPHD8780145 145 80 8.7 8 11000 3.7
    LPHD8785183 183 85 8.7 10 15000 3.7
    LPHD882448 48 24 8.8 30 850 3.7
    LPHD882892 92 28 8.8 10 2450 3.7
    LPHD882978 78 29 8.8 1 2100 3.7
    LPHD8830105 105 30 8.8 5 3250 3.7
    LPHD883048 48 30 8.8 15 1100 3.7
    LPHD883082 82 30 8.8 20 1800 3.7
    LPHD8834122 122 34 8.8 20 3400 3.7
    LPHD8834122 122 34 8.8 10 4000 3.7
    LPHD883465 65 34 8.8 1 2250 3.7
    LPHD883476 76 34 8.8 20 2200 3.7
    LPHD8842126 126 42 8.8 20 4400 3.7
    LPHD8842126 126 42 8.8 35 4000 3.7
    LPHD8843128 128 43 8.8 20 4250 3.7
    LPHD8843128 128 43 8.8 30 4000 3.7
    LPHD8845150 150 45 8.8 30 5600 3.7
    LPHD884765 65 47 8.8 1 3000 3.7
    LPHD884940 40 49 8.8 30 1300 3.7
    LPHD884996 96 49 8.8 5 4900 3.7
    LPHD8850140 140 50 8.8 10 7150 3.7
    LPHD885097 97 50 8.8 5 4900 3.7
    LPHD885998 98 59 8.8 10 5300 3.7
    LPHD8864159 159 64 8.8 15 10000 3.7
    LPHD8865132 132 65 8.8 1 6000 3.7
    LPHD8867222 222 67 8.8 5 17000 3.7
    LPHD886868 68 68 8.8 1 4800 3.7
    LPHD8870170 170 70 8.8 1 10000 3.7
    LPHD8870175 175 70 8.8 10 12000 3.7
    LPHD887768 68 77 8.8 8 4700 3.7
    LPHD892442 42 24 8.9 15 800 3.7
    LPHD892448 48 24 8.9 30 850 3.7
    LPHD893048 48 30 8.9 15 1100 3.7
    LPHD8931105 105 31 8.9 5 3400 3.7
    LPHD8934106 106 34 8.9 35 2650 3.7
    LPHD8934106 106 34 8.9 30 3000 3.7
    LPHD893496 96 34 8.9 25 2400 3.7
    LPHD8936128 128 36 8.9 15 4200 3.7
    LPHD8943158 158 43 8.9 5 7600 3.7
    LPHD8945150 150 45 8.9 25 5300 3.7
    LPHD8945150 150 45 8.9 20 5500 3.7
    LPHD895592 92 55 8.9 5 5200 3.7
    LPHD896077 77 60 8.9 1 5000 3.7
    LPHD8967217 217 67 8.9 15 13900 3.7
    LPHD8967220 220 67 8.9 15 14000 3.7



    Alta Scarico C-rating Batteria Litio Polimeri
    spessore 9.0mm to 9.9mm, 1000mAh to 2100mAh, 1C to 40C

    Modello lunghezza
    (mm)
    Altezza
    (mm)
    spessore
    (mm)
    C-rating capacità
    (mAh)
    tensione
    (V)
    LPHD9034106 106 34 9.0 35 2650 3.7
    LPHD903562 62 35 9.0 20 1550 3.7
    LPHD903562 62 35 9.0 35 1550 3.7
    LPHD9036128 128 36 9.0 20 3800 3.7
    LPHD904172 72 41 9.0 1 2300 3.7
    LPHD9042124 124 42 9.0 1 6000 3.7
    LPHD9042126 126 42 9.0 20 4500 3.7
    LPHD9042126 126 42 9.0 20 3800 3.7
    LPHD9043128 128 43 9.0 20 4400 3.7
    LPHD9043158 158 43 9.0 5 7600 3.7
    LPHD904360 60 43 9.0 20 2100 3.7
    LPHD9045150 150 45 9.0 30 5000 3.7
    LPHD9045150 150 45 9.0 30 5200 3.7
    LPHD9045180 180 45 9.0 20 7050 3.7
    LPHD905290 90 52 9.0 1 3900 3.7
    LPHD905686 86 56 9.0 20 4000 3.7
    LPHD9059156 156 59 9.0 1 10000 3.7
    LPHD9059156 156 59 9.0 30 8000 3.7
    LPHD906077 77 60 9.0 1 5000 3.7
    LPHD9070170 170 70 9.0 1 10000 3.7
    LPHD9070175 175 70 9.0 5 12500 3.7
    LPHD913096 96 30 9.1 5 3150 3.7
    LPHD9145180 180 45 9.1 20 7050 3.7
    LPHD9159156 156 59 9.1 5 10000 3.7
    LPHD9170175 175 70 9.1 10 12000 3.7
    LPHD923048 48 30 9.2 30 1000 3.7
    LPHD923085 85 30 9.2 1 2000 3.7
    LPHD9234122 122 34 9.2 20 3350 3.7
    LPHD923496 96 34 9.2 20 2100 3.7
    LPHD9236128 128 36 9.2 15 4750 3.7
    LPHD9242125 125 42 9.2 40 4000 3.7
    LPHD9242126 126 42 9.2 25 4200 3.7
    LPHD9242126 126 42 9.2 20 4600 3.7
    LPHD924358 58 43 9.2 20 2000 3.7
    LPHD9245150 150 45 9.2 30 6000 3.7
    LPHD9245150 150 45 9.2 30 5550 3.7
    LPHD9245180 180 45 9.2 20 7050 3.7
    LPHD924590 90 45 9.2 1 5000 3.7
    LPHD9246143 143 46 9.2 30 6000 3.7
    LPHD9259156 156 59 9.2 30 8000 3.7
    LPHD9267100 100 67 9.2 1 5000 3.7
    LPHD9270170 170 70 9.2 5 12500 3.7
    LPHD9270175 175 70 9.2 10 12000 3.7
    LPHD927560 60 75 9.2 1 4700 3.7
    LPHD9276119 119 76 9.2 20 6400 3.7
    LPHD9282262 262 82 9.2 8 24000 3.7
    LPHD933048 48 30 9.3 15 1100 3.7
    LPHD933496 96 34 9.3 20 2700 3.7
    LPHD9342126 126 42 9.3 20 4600 3.7
    LPHD9342126 126 42 9.3 10 5000 3.7
    LPHD9343128 128 43 9.3 20 4800 3.7
    LPHD9345123 123 45 9.3 8 6300 3.7
    LPHD9345135 135 45 9.3 15 6100 3.7
    LPHD9345150 150 45 9.3 25 5800 3.7
    LPHD9345150 150 45 9.3 35 5800 3.7
    LPHD935265 65 52 9.3 1 3950 3.7
    LPHD9355175 175 55 9.3 1 8000 3.7
    LPHD937768 68 77 9.3 8 4900 3.7
    LPHD937780 80 77 9.3 8 6000 3.7
    LPHD942072 72 20 9.4 1 1550 3.7
    LPHD9436128 128 36 9.4 20 4000 3.7
    LPHD9438110 110 38 9.4 20 3800 3.7
    LPHD9442126 126 42 9.4 20 4800 3.7
    LPHD9442126 126 42 9.4 20 5200 3.7
    LPHD9445135 135 45 9.4 15 6100 3.7
    LPHD944590 90 45 9.4 20 3600 3.7
    LPHD9449135 135 49 9.4 25 5800 3.7
    LPHD945170 70 51 9.4 1 4000 3.7
    LPHD945686 86 56 9.4 1 6000 3.7
    LPHD9459134 134 59 9.4 1 10000 3.7
    LPHD9467100 100 67 9.4 1 7800 3.7
    LPHD9470175 175 70 9.4 10 12000 3.7
    LPHD9477123 123 77 9.4 20 6400 3.7
    LPHD952595 95 25 9.5 20 1500 3.7
    LPHD953048 48 30 9.5 15 1100 3.7
    LPHD953496 96 34 9.5 25 2600 3.7
    LPHD9536128 128 36 9.5 8 5000 3.7
    LPHD9536128 128 36 9.5 20 4000 3.7
    LPHD9544100 100 44 9.5 20 4000 3.7
    LPHD9545123 123 45 9.5 8 6300 3.7
    LPHD9545135 135 45 9.5 15 5800 3.7
    LPHD9556117 117 56 9.5 15 6300 3.7
    LPHD955686 86 56 9.5 20 4500 3.7
    LPHD9564159 159 64 9.5 15 10000 3.7
    LPHD9567220 220 67 9.5 1 17500 3.7
    LPHD9570170 170 70 9.5 5 15000 3.7
    LPHD9570170 170 70 9.5 10 12000 3.7
    LPHD9590190 190 90 9.5 5 21000 3.7
    LPHD963476 76 34 9.6 1 3000 3.7
    LPHD963476 76 34 9.6 20 2200 3.7
    LPHD9642126 126 42 9.6 35 4700 3.7
    LPHD9642126 126 42 9.6 30 5000 3.7
    LPHD9643128 128 43 9.6 20 5200 3.7
    LPHD9645135 135 45 9.6 20 5750 3.7
    LPHD9645135 135 45 9.6 15 5800 3.7
    LPHD964590 90 45 9.6 20 3500 3.7
    LPHD9646143 143 46 9.6 5 8000 3.7
    LPHD9659156 156 59 9.6 30 8000 3.7
    LPHD9659156 156 59 9.6 5 10000 3.7
    LPHD9664155 155 64 9.6 15 10000 3.7
    LPHD9670135 135 70 9.6 5 10000 3.7
    LPHD9670170 170 70 9.6 1 10000 3.7
    LPHD9675175 175 75 9.6 5 15000 3.7
    LPHD9742126 126 42 9.7 20 4800 3.7
    LPHD9742126 126 42 9.7 20 5000 3.7
    LPHD9742126 126 42 9.7 30 5000 3.7
    LPHD9742126 126 42 9.7 10 5900 3.7
    LPHD9743128 128 43 9.7 35 4300 3.7
    LPHD974356 56 43 9.7 20 2100 3.7
    LPHD974360 60 43 9.7 20 2100 3.7
    LPHD974590 90 45 9.7 5 5000 3.7
    LPHD975265 65 52 9.7 5 4000 3.7
    LPHD9759156 156 59 9.7 5 10000 3.7
    LPHD9759156 156 59 9.7 30 8000 3.7
    LPHD9764155 155 64 9.7 15 10000 3.7
    LPHD9764159 159 64 9.7 15 10000 3.7
    LPHD9770170 170 70 9.7 1 15000 3.7
    LPHD982741 41 27 9.8 1 950 3.7
    LPHD983758 58 37 9.8 1 2500 3.7
    LPHD984050 50 40 9.8 1 2000 3.7
    LPHD9842126 126 42 9.8 35 5200 3.7
    LPHD9843128 128 43 9.8 20 4800 3.7
    LPHD9845119 119 45 9.8 8 6300 3.7
    LPHD9845135 135 45 9.8 8 7000 3.7
    LPHD9846125 125 46 9.8 5 6950 3.7
    LPHD9859156 156 59 9.8 30 8000 3.7
    LPHD9859156 156 59 9.8 5 10000 3.7
    LPHD9863139 139 63 9.8 5 10000 3.7
    LPHD9864155 155 64 9.8 15 10000 3.7
    LPHD9864159 159 64 9.8 15 10000 3.7
    LPHD986870 70 68 9.8 1 6000 3.7
    LPHD9870170 170 70 9.8 1 10000 3.7
    LPHD9870170 170 70 9.8 10 12000 3.7
    LPHD987776 76 77 9.8 1 7200 3.7
    LPHD9890190 190 90 9.8 8 21000 3.7
    LPHD989092 92 90 9.8 15 8000 3.7
    LPHD9942126 126 42 9.9 20 5000 3.7
    LPHD9945135 135 45 9.9 8 7000 3.7
    LPHD998273 73 82 9.9 15 6100 3.7



    Alta Scarico C-rating Batteria Litio Polimeri
    spessore 10mm to 19mm, 1700mAh to 29500mAh, 1C to 40C

    Modello lunghezza
    (mm)
    Altezza
    (mm)
    spessore
    (mm)
    C-rating capacità
    (mAh)
    tensione
    (V)
    LPHD103450 50 34 10.0 1 1800 3.7
    LPHD103450 50 34 10.0 8 1700 3.7
    LPHD103476 76 34 10.0 15 2400 3.7
    LPHD103992 92 39 10.0 20 3250 3.7
    LPHD1042126 126 42 10.0 20 5000 3.7
    LPHD1045135 135 45 10.0 15 6100 3.7
    LPHD1045135 135 45 10.0 8 7000 3.7
    LPHD1045150 150 45 10.0 35 5800 3.7
    LPHD104694 94 46 10.0 1 4600 3.7
    LPHD1047115 115 47 10.0 8 6300 3.7
    LPHD1048150 150 48 10.0 5 8500 3.7
    LPHD104992 92 49 10.0 1 6000 3.7
    LPHD112448 48 24 11.0 20 1000 3.7
    LPHD1142126 126 42 11.0 25 5500 3.7
    LPHD1142126 126 42 11.0 15 5600 3.7
    LPHD1145135 135 45 11.0 8 7000 3.7
    LPHD1164159 159 64 11.0 5 12500 3.7
    LPHD119092 92 90 11.0 15 8000 3.7
    LPHD123864 64 38 12.0 1 2700 3.7
    LPHD1242126 126 42 12.0 20 5200 3.7
    LPHD1242126 126 42 12.0 20 5450 3.7
    LPHD1242126 126 42 12.0 35 4700 3.7
    LPHD1245135 135 45 12.0 15 6100 3.7
    LPHD1270175 175 70 12.0 5 15000 3.7
    LPHD1342124 124 42 13.0 10 6000 3.7
    LPHD1342126 126 42 13.0 25 5100 3.7
    LPHD1342126 126 42 13.0 15 6100 3.7
    LPHD1342126 126 42 13.0 10 6300 3.7
    LPHD1342126 126 42 13.0 30 5300 3.7
    LPHD1342126 126 42 13.0 20 5200 3.7
    LPHD1342126 126 42 13.0 30 5000 3.7
    LPHD1345150 150 45 13.0 20 6900 3.7
    LPHD1347115 115 47 13.0 8 6850 3.7
    LPHD1347115 115 47 13.0 8 6300 3.7
    LPHD1355270 270 55 13.0 1 21000 3.7
    LPHD1355270 270 55 13.0 5 21000 3.7
    LPHD1363139 139 63 13.0 5 11300 3.7
    LPHD1370170 170 70 13.0 1 16000 3.7
    LPHD1375175 175 75 13.0 15 15000 3.7
    LPHD1390190 190 90 13.0 5 21500 3.7
    LPHD1442124 124 42 14.0 20 5500 3.7
    LPHD1442124 124 42 14.0 35 5000 3.7
    LPHD1442126 126 42 14.0 30 5000 3.7
    LPHD144590 90 45 14.0 5 5000 3.7
    LPHD1447115 115 47 14.0 8 6300 3.7
    LPHD1475175 175 75 14.0 15 15000 3.7
    LPHD153288 88 32 15.0 8 3400 3.7
    LPHD153288 88 32 15.0 5 3400 3.7
    LPHD1542124 124 42 15.0 20 5500 3.7
    LPHD1542124 124 42 15.0 30 5000 3.7
    LPHD1542126 126 42 15.0 30 5000 3.7
    LPHD1542126 126 42 15.0 40 4700 3.7
    LPHD1542126 126 42 15.0 20 5200 3.7
    LPHD1542126 126 42 15.0 10 6000 3.7
    LPHD1542126 126 42 15.0 15 6600 3.7
    LPHD1543128 128 43 15.0 25 5100 3.7
    LPHD1543128 128 43 15.0 15 5600 3.7
    LPHD1543128 128 43 15.0 10 6200 3.7
    LPHD1570145 145 70 15.0 5 12500 3.7
    LPHD1575175 175 75 15.0 10 15000 3.7
    LPHD1575175 175 75 15.0 15 15000 3.7
    LPHD1590190 190 90 15.0 8 21000 3.7
    LPHD162072 72 20 16.0 5 1800 3.7
    LPHD1630200 200 30 16.0 5 32200 3.7
    LPHD1642126 126 42 16.0 15 6600 3.7
    LPHD1642124 124 42 16.0 20 5500 3.7
    LPHD1643126 126 43 16.0 15 6350 3.7
    LPHD1645150 150 45 16.0 20 6900 3.7
    LPHD166479 79 64 16.0 15 5700 3.7
    LPHD1675175 175 75 16.0 10 15000 3.7
    LPHD1722185 185 22 17.0 8 25500 3.7
    LPHD1730185 185 30 17.0 8 27500 3.7
    LPHD1730200 200 30 17.0 8 29500 3.7
    LPHD1742126 126 42 17.0 20 5700 3.7
    LPHD1742126 126 42 17.0 8 7000 3.7
    LPHD1742126 126 42 17.0 15 6600 3.7
    LPHD1743126 126 43 17.0 15 6350 3.7
    LPHD1743128 128 43 17.0 20 5600 3.7
    LPHD1745150 150 45 17.0 20 6900 3.7
    LPHD1775175 175 75 17.0 10 15000 3.7
    LPHD1799185 185 99 17.0 8 29500 3.7
    LPHD1790185 185 90 17.0 8 21000 3.7
    LPHD1790190 190 90 17.0 8 21000 3.7
    LPHD1790190 190 90 17.0 8 22500 3.7
    LPHD1790190 190 90 17.0 5 24500 3.7
    LPHD1790215 215 90 17.0 8 24000 3.7
    LPHD184180 80 41 18.0 15 4200 3.7
    LPHD1842124 124 42 18.0 20 5700 3.7
    LPHD1842124 124 42 18.0 35 5200 3.7
    LPHD1842126 126 42 18.0 8 7000 3.7
    LPHD1842126 126 42 18.0 35 5200 3.7
    LPHD1842126 126 42 18.0 15 6600 3.7
    LPHD1842126 126 42 18.0 10 6550 3.7
    LPHD1843126 126 43 18.0 5 7250 3.7
    LPHD1842126 126 42 18.0 15 6300 3.7
    LPHD1875170 170 75 18.0 10 15000 3.7
    LPHD1875175 175 75 18.0 10 15000 3.7
    LPHD1875175 175 75 18.0 10 16800 3.7
    LPHD1885155 155 85 18.0 10 16800 3.7
    LPHD1890190 190 90 18.0 8 21000 3.7
    LPHD1940121 121 40 19.0 8 6050 3.7
    LPHD1942126 126 42 19.0 8 7000 3.7
    LPHD1942126 126 42 19.0 10 6550 3.7
    LPHD1942126 126 42 19.0 15 6500 3.7
    LPHD1942126 126 42 19.0 15 6300 3.7
    LPHD1942126 126 42 19.0 35 5200 3.7
    LPHD1943126 126 43 19.0 5 7250 3.7
    LPHD1943126 126 43 19.0 15 6350 3.7
    LPHD196479 79 64 19.0 15 5600 3.7
    LPHD1985155 155 85 19.0 10 16800 3.7



    Alta Scarico C-rating Batteria Litio Polimeri
    spessore 20mm to 22mm, 2000mAh to 7950mAh, 5C to 30C

    Modello lunghezza
    (mm)
    Altezza
    (mm)
    spessore
    (mm)
    C-rating capacità
    (mAh)
    tensione
    (V)
    LPHD202978 78 29 20 30 2000 3.7
    LPHD204180 80 41 20 15 3900 3.7
    LPHD2042126 126 42 20 8 6900 3.7
    LPHD2042126 126 42 20 15 6000 3.7
    LPHD2042126 126 42 20 15 6300 3.7
    LPHD2042126 126 42 20 15 6600 3.7
    LPHD2042126 126 42 20 10 6550 3.7
    LPHD2042126 126 42 20 8 7500 3.7
    LPHD2042126 126 42 20.0 8 7000 3.7
    LPHD2042126 126 42 20.0 15 6950 3.7
    LPHD2042126 126 42 20.0 10 7000 3.7
    LPHD2043126 126 43 20 5 7950 3.7
    LPHD2043127 127 43 20.0 15 7000 3.7
    LPHD206479 79 64 2.0 10 5900 3.7
    LPHD2142126 126 42 21.0 15 6300 3.7
    LPHD2142126 126 42 21.0 10 6550 3.7
    LPHD2143126 126 43 21 5 7500 3.7
    LPHD2242126 126 42 22.0 20 6050 3.7
    Fill out my online form.
Home | Azienda | Batteria | Hot news | Supporto | Applicazioni | Contattarci | Sitemap
© 2002 - 2016 LiPol Battery Co., Ltd. Tutti i diritti riservati.
